Basic Use Netscreen commands



ScreenOS  JUNOS  Notes
Session & Interface counters
get session > show security flow session
get interface > show interface terse
get counter stat > show interface extensive
get counter stat <interface> > show interface <interface> extensive
clear counter stat > clear interface statistics <interface>
Debug & Snoop
debug flow basic # edit security flow -creates debugs in default file name: /var/log/security-traceSee KB16108 for traceoptions info.
# set traceoptions flag basic-datapath
# commit
set ff # edit security flow Packet-drop is a feature that will be added
# set traceoptions packet-filter
get ff > show configuration | match packet-filter | display set
get debug > show configuration | match traceoptions | display set
get db stream View stored log: (recommended option) ‘monitor stop’ stops real-time view , but debugs are still collected in log files
> show log <file name> (enter h to see help options)
> show log security-trace (to view ‘security flow’ debugs)
> show log kmd (to view ‘security ike’ debugs)View real-time: (use this option with caution)
> monitor start <debugfilename>
ESC-Q (to pause real-time output to screen)
clear db > clear log <filename> (clears contents of file) Use ‘file delete <filename> to actually delete file>
undebug <debug> (stops collecting debugs) # edit security flow Deactivate makes it easier to enable/disable.Use activate traceoptions to activate.
# deactivate traceoptions OR # delete traceoptions (at the particular hierarchy)
# commit
undebug all Not available. You need to deactivate or delete traceoptions separately.
debug ike detail # edit security ike -creates debugs in default file name: kmd
# set traceoptions flag ike
# commit
snoop (packets THRU the JUNOS device) Use Packet Capture feature: http://www.juniper.net/techpubs/software/junos-security/junos-security95/junos-security-admin-guide/config-pcap-chapter.html#config-pcap-chapter - Not supported on SRX 3×00/5×00 yet
snoop (packets TO the JUNOS device) > monitor traffic interface <int> layer2-headers -Only captures traffic destined for the RE of router itself.- Excludes PING .
write-file option (hidden)
read-file (hidden)
Event Logs
get event > show log messages
> show log messages | last 20 (helpful cmd because newest log entries are at end of file)
get event | include <string> > show log messages | match <string> Note: There is not an equivalent command for ‘get event include <string>’.
> show log messages | match “<string> | <string> | <string>”
Examples: match displays only the lines that contains the string
> show log messages | match “error | kernel | panic”
> show log messages | last 20 | find error find displays output starting from the first occurrence of the string
clear event > clear log messages
  > show log
Config & Software upgrade
get config > show config (program structured format)
> show config | display set (set command format)
get license > show system license keys
get chassis (serial numbers) > show chassis hardware detail > show chas environment
> show chas routing-engine
exec license > request system license [add | delete |save]
unset allreset load factory-default See KB15725.
set system root-authentication plain-text-passsword
commit and-quit
request system reboot
load config from tftp <tftp_server> <configfile> > start shell and FTP config to router, i.e. /var/tmp/test.cfg. Then -TFTP is not supported. Use only FTP, HTTP, or SCP.
# load override /var/tmp/test.cfg (or full path of config file)
load software from tftp <tftp_server> <screenosimage> to flash > request system software add -TFTP is not supported. Use only FTP. HTTP, or SCP.
Example: -Use ‘request system software rollback’ to rollback to previous s/w packageSee KB16652.
request system software add ftp:10.10.10.129/jsr/junos-srxsme-9.5R1.8-domestic.tgz reboot
save # commit OR
# commit and-quit
reset > request system reboot
Policy
get policy > show security policies
get policy from <zone> to <zone> > show security policies from <zone> to <zone>
VPN
get ike cookie > show security ike security-associations
get sa > show security ipsec security-associations > show security ipsec stat
clear ike cookie > clear security ike security-associations
clear sa > clear security ipsec security-associations
NSRP
get nsrp > show chassis cluster status
> show chassis cluster interfaces
> show chassis cluster status redundancy-group <group>
exec nsrp vsd <vsd> mode backup (on master) see KB5885 > request chassis cluster failover redundancy-group <group> node <node>
  > request chassis cluster failover reset redundancy-group <group>
DHCP
get dhcp client > show system services dhcp client See KB15753.
exec dhcp client <int> renew > request system services dhcp renew (or release)
Routing
get route > show route
get route ip <ipaddress> > show route <ipaddress>
get vr untrust-vr route > show route instance untrust-vr
get ospf nei > show ospf neighbor
set route 0.0.0.0/0 interface <int> gateway <ip> # set routing-options static route 0.0.0.0/0 next-hop <ip> See KB16572.
NAT
get vip > show security nat destination-nat summary
get mip > show security nat static-nat summary
get dip > show security nat source-nat summary
> show security nat source-nat pool <pool>
Other
get perf cpu > show chassis routing-engine
get net-pak s > show system buffers
get file > show system storage
get alg > show configuration groups junos-defaults applications All pre-defined applications are located within the hidden group junos-defaults. If any ALGs are applied to the pre-defined applications, they will also be displayed with this command.
get service > show configuration groups junos-defaults applications
get tech > request support information
set console page 0 > set cli screen-length 0

  > file list <path> Shows directory listing.
Example: file list /var/tmp/ Note that / is needed at end of path

  # = configuration mode prompt
  > = operational mode prompt
